CAD DRAFTING SERVICES

We have an extensive experience on CAD drafting of highway structures such as :

• Bridge decks, piers, abutments, approach slabs
• Underpass and braiding structures
• Reinforced concrete box and pipe culverts, wing walls
• Mechanically Stabilized Earth (MSE) or Reinforced Concrete retaining walls
•  Advance Directional Signs (Overhead and Ground Mounted)   layout and foundation details

Our CAD Drafting Services for Commercial and Residential Buildings are as below :

• Structural Floor Plans
• Foundation Layouts and Reinforcement Details
• Columns Application Layout and Schedules
• Slabs Reinforcement Details
• RC Beams Reinforcement Details
• Bar Bending Schedules

 Our CAD Drafting Services for Road Construction works are as below :

• Road Layout with Google Earth imported imagery option
• Setting out layouts and details
• Typical and detailed cross sections
• Standard Traffic Signs and Directional Signs General Arrangement Layout
• Traffic Diversion Layouts
• Preparation of General Arrangement drawings for Civil and Infrastructure works

 Our CAD Drafting Services for Infrastructure works are as below :

• Wet and Dry Utilities networks layouts, profiles and typical sections
• Valve Chambers and Precast Manholes reinforcement details.
• Utility corridor layouts showing superimposed utilities within their assigned corridors.
• Road crossing ducts layouts, setting out details and sections.
